An 18,000 BTU (1.5-ton) ductless mini split heats and cools a single room up to about 400 square feet. That's roughly 50% more capacity than a 12,000 BTU unit, so it handles the larger living rooms, master suites, garages, and studios that smaller systems struggle to keep up with.
This model runs on a dedicated 208/230V circuit — the same voltage your contractor already uses for central AC. No 230V where you need it? Filterbuy is the only brand that also makes an 18,000 BTU mini split for a standard 115V outlet.
Quick size guide:
Shop the 18,000 BTU System →
Not sure 18,000 BTU is the right fit? Answer 5 quick questions and we'll match you to the right size.
This 1.5-ton ductless system delivers year-round heating and cooling up to 850 square feet, with a variable speed inverter for efficiency and full app control from your phone. It ships free in 2 days.
Every unit comes with free 2-day shipping, a 5-year compressor warranty, professional-grade construction, and built-in app control — everything you need, backed by the air quality experts.
The Filterbuy 18,000 BTU (1.5-ton) ductless mini split carries a 17 SEER2 efficiency rating and runs on a dedicated 208/230V, 1-phase, 60 Hz circuit. Its variable-speed DC inverter compressor covers up to 850 square feet as a single-zone, wall-mounted unit.
Smart features include mobile app control, built-in WiFi, a self-cleaning mode, and sleep mode. The system ships free anywhere in the US in 2 days, complete with everything a licensed HVAC contractor needs for installation — including the dedicated 230V circuit with disconnect box.
It comes backed by a 7-year compressor and 3-year parts warranty, with professional installation required for full coverage.
A 12,000 BTU mini split tops out around 550 square feet. If your living room, garage, or master bedroom has already proved one wrong, this is the system you've been looking for.
At 1.5 tons, this unit covers open-plan living rooms, oversized master suites, studio apartments, garages, and workshops up to 850 square feet — delivering year-round heating and cooling from a single wall-mounted unit.
It runs at 208/230V, drawing low amperage on the same voltage your HVAC contractor uses for central air conditioners, heat pumps, and large appliances. No special setup, no unfamiliar process. Your tech already works with 230V on every job.
The variable speed DC inverter compressor adjusts output continuously — ramping up for rapid cool-down, then pulling back to hold temperature without the energy spikes that come with fixed-speed systems.
Built-in WiFi and app control let you adjust temperature, set schedules, and monitor operation from your phone, whether you're across the room or across town. That's especially useful for garages and workshops you don't check every day.
Every unit ships free in 2 days, with everything your contractor needs already in the box.
Every major HVAC manufacturer specs their 18,000 BTU systems at 230V. There's a reason contractors expect it — and it comes down to physics, not convention.
At 230V, a 1.5-ton system draws roughly 8–12 amps — compared to 15–18+ amps at 115V for the same cooling output. Lower current means a smaller circuit breaker, thinner wire gauge, and less load on your electrical panel.
Higher voltage means less resistive line loss over the wire run from your electrical panel to the outdoor unit. For garages, workshops, and detached structures where that distance can be significant, 230V delivers more of the power you're paying for.
230V is the same voltage used for central air conditioners, heat pumps, and large appliances. Your HVAC contractor installs 230V equipment on every job — no special knowledge, no unfamiliar process, no surprises.
At 18,000 BTU, this system delivers 50% more cooling and heating power than a standard 1-ton (12,000 BTU) mini split. That means it handles the rooms that smaller units can't — open-plan living areas, oversized garages, studio apartments, and master bedrooms with high ceilings up to 400 square feet. If you've outgrown a 12K, this is the next step up.
The DC inverter compressor adjusts speed continuously to match your room's actual demand. It runs at full capacity for rapid cooling, then pulls back to hold temperature without the energy waste of on/off cycling. The result: lower energy bills, more consistent comfort, quieter operation, and less wear on the compressor over the system's life.
Running at 230 volts, this 1.5-ton system draws less than most kitchen appliances. That means a smaller circuit breaker, thinner wire, and a cleaner electrical installation overall. For contractors, it's a familiar setup. For homeowners, it has lower installation material costs.
Built-in WiFi and a dedicated mobile app put temperature control in your pocket. Adjust settings, set schedules, switch between heating and cooling, and monitor operation from anywhere. Particularly useful for garages, workshops, and guest spaces you don't visit every day.
The built-in heat pump reverses the refrigerant cycle to handle both heating in winter and cooling in summer — one system, all four seasons. You won't need separate space heaters or supplemental equipment to get through the cold months.
An automated cleaning cycle dries the evaporator coil after operation, stopping mold and bacteria from building up and degrading both air quality and efficiency. At 1.5 tons, this system moves 50% more air than a 12K model, which makes regular self-cleaning especially important for long-term performance and the quality of the air you're breathing.
Spaces where a 12,000 BTU unit falls short but central air is overkill — or simply unavailable. The 1.5-ton capacity fills that gap with powerful, efficient climate control. Open floor plans, great rooms, and combined living/dining areas up to 850 square feet are all within reach.
Most garages already have 230V power for tools, welders, air compressors, or EV chargers. Adding an 18,000 BTU mini split turns a seasonal space into a year-round productive workshop. The variable speed compressor handles the wide temperature swings garages are known for, and app control lets you pre-condition the space before you walk in.
Large master bedrooms, rooms with cathedral ceilings, or suites with attached sitting areas that have overwhelmed a standard 12K unit. Sleep mode and whisper-quiet operation at low speed keep things comfortable through the night without disrupting your rest.
Single-zone coverage for open-concept living spaces. One system handles the entire studio — kitchen, living area, and sleeping space — with the capacity to stay comfortable even when cooking adds extra heat load.
Back houses, ADUs, attic conversions, enclosed porches — anywhere without ductwork that needs serious climate control. New construction typically includes 230V circuits, which makes installation straightforward for your contractor.
Retail shops, small offices, server rooms, barber shops, and private studios. Commercial spaces almost universally run on 230V, and an 18,000-BTU mini-split delivers efficient, independently controlled climate management without the cost of a full commercial HVAC system.
Everything your HVAC contractor needs for a complete professional installation:
Indoor wall-mount air handler unit
Outdoor condenser/compressor unit
Pre-flared copper line set
Power supply/communication cable
Wireless remote control
Mounting bracket and hardware
Installation instructions and wiring diagram
Drain hose and fittings
Professional HVAC installation is required, and self-installation voids the manufacturer's warranty. Everything your contractor needs comes in the box — and with free 2-day shipping, they won't be waiting on parts.
Electrical Requirements: This unit requires a dedicated 208/230V, 1-phase, 60 Hz circuit with a disconnect box installed near the outdoor unit. It's the same electrical setup used for central air conditioners and large appliances — standard work for any licensed electrician.
Filterbuy has shipped millions of air filters directly from our U.S. factories to homeowners who care about what's in their air. That same obsession with indoor air quality carries over into every mini-split we sell — not just the unit, but the maintenance guidance and support that keep it performing for years.
At 1.5 tons, this system moves 50% more air than a standard 12K unit — which means its filter picks up dust, dander, and allergens faster. Regular maintenance at this capacity isn't optional; it's what separates a system that runs strong for a decade from one that starts struggling at year five. We don't just tell you that — we give you the tools to stay on schedule.
2-day shipping on every order — most competitors ship in 3–10 business days
Expert maintenance guidance — tailored to higher-capacity systems
Filter cleaning reminders — so the maintenance that protects your investment stays on track
Access to our IAQ resource library — with guides on indoor air quality, allergens, and system care
Real customer support — from people who understand air quality and HVAC
Other mini split retailers send you a box and move on. We give you options no one else in this category has, and we back them with air quality expertise that's been central to everything Filterbuy builds.
The Filterbuy 18,000 BTU mini split effectively cools and heats rooms up to 850 square feet — large living rooms, open studios, master bedrooms, single-car garages, and workshops. Filterbuy's conservative rating reflects real-world performance for genuine comfort, not inflated marketing numbers.
Yes. This model requires a dedicated 208/230V circuit with a disconnect box installed near the outdoor unit. It's the same voltage that powers central air conditioners, clothes dryers, and large power tools — standard work for any licensed HVAC contractor or electrician.
Total installed costs for an 18,000 BTU mini split system typically run approximately $4,500–$6,500, covering the unit, professional installation labor, electrical work, and materials. Filterbuy's equipment cost for this unit is $899 is competitive within the market. Your final project cost will depend on your contractor's labor rates, your home's existing electrical setup, and your location.
Yes. This system operates as a heat pump — it cools in summer and heats in winter from a single unit. The compressor reverses the refrigerant cycle to pull heat from outdoor air and deliver it inside. One system handles year-round comfort in most climates, with no separate heating equipment required.
"Ton" is an HVAC sizing unit based on cooling capacity: 1 ton equals 12,000 BTU. This 18,000 BTU unit is a 1.5-ton system — 50% more cooling and heating capacity than a standard 1-ton (12,000 BTU) mini split. The extra capacity makes it the right call for larger rooms, high-ceiling spaces, and areas with higher heat loads that overwhelm smaller units.
At approximately 1,150 watts, a 17 SEER2 rating, and 8 hours of daily use at the national average electricity rate of $0.15/kWh, the estimated monthly cost works out to around $54. In practice, your costs will likely run lower — the variable speed inverter uses less energy during mild weather and when holding temperature, only drawing peak wattage during initial cool-down.
No. Professional installation by a licensed HVAC contractor is required, and self-installation voids the manufacturer's warranty. Filterbuy's professional-grade systems need proper refrigerant handling, vacuum testing, leak checking, and certified electrical connections. Everything your contractor needs comes in the box, and with free 2-day shipping, there's no waiting on parts.
For context, rustling leaves measure about 24 dBA, and a quiet library sits around 40 dBA. While 1.5-ton systems are slightly louder than 12K models at full output, the variable speed compressor spends most of its time at partial load — where noise drops considerably. This unit is dramatically quieter than window air conditioners, which typically run 50–70 dBA.
Yes, this unit has multi-layer healthy filtration that captures dust, pet dander, and airborne particles, with a built-in filter-cleaning reminder. At 1.5 tons, the system moves 50% more air than a 12,000 BTU model — which means the filter picks up contaminants faster. Clean it on the schedule the reminder prompts. Regular maintenance keeps airflow strong, efficiency high, and your indoor air quality where it should be. Filterbuy's air quality expertise makes a real difference here. We give you access to maintenance guides, filter care reminders, and the knowledge to keep your system running efficiently for years.
This unit includes a 7-year compressor warranty and a 3-year parts warranty when professionally installed by a licensed HVAC contractor. Professional installation is a warranty requirement — self-installation voids coverage. Filterbuy's customer support team is available to help with any warranty questions or claims.
The Filterbuy 18,000 BTU ductless mini split in 230V up to 850 square feet. It runs a variable speed inverter for efficiency, puts full climate control in your phone via the app, and arrives backed by the air quality expertise that's been central to everything Filterbuy builds. Seven-year compressor / three-year parts warranty. Ships free in 2 days. Everything your contractor needs is already in the box.
